Description

Challenger’s 14,000 lb. closed-front drive-on 4-post lift features a low approach angle and wide runways for easy approach. It also has one of the highest rise in the industry and durable column construction. We designed the 4P14 for versatility, with louvered approach ramps as well as in two lengths. A range of optional accessories can help you accommodate just about anything that comes in for service.

ALI/ETL certified.
Features & Benefits
• 14,000 lb. lift capacity
• Closed front design with either 182.5″ or 210” (extended) wheelbase to accommodate long vehicles
• 20″ wide runways aid for drive-on confidence
• Louvered approach ramps provide superior traction for driving vehicles on and off ramp
• 78″ rise height, among the highest rise in the industry, provides maximum head room for working underneath vehicles
• 14-level locking positions, allowing ergonomic working height for technicians to increase productivity and minimize fatigue
• Powder coat finish provides long-lasting durability
• Available with red or blue columns
Specs
Model Number 4P14EFX 4P14XFX
Lifting Capacity 14,000 lbs. 14,000 lbs.
Open or Closed Front Closed Closed
Max. Wheelbase 182.5” 210”
Rise Height 78” 78”
Overall Length 245.75” 273.25”
Overall Width 130.75” 130.75”
Inside Columns 116” 116”
Between Columns 196” 223.5”
Height of Columns 90.5” 90.5”
Width of Runways 20” 20”
Height of Runways 7.25” 7.25”
Width Between Runways 40” / 43” 40” / 43”
Air Supply Required 90-120 psi 90-120 psi
Motor / Voltage 2HP, 208v-230v, 60Hz, 1Ph 2HP, 208v-230v, 60Hz, 1Ph
Speed or Rise 90 s 90 s
Min. Recomm. Bay Size 12’ x 24’ 12’ x 26’
ALI/ETL Certified Yes Yes
Colors Available Red, Blue Red, Blue
Accessories
Alignment Accessories
Part No. Description
RJ7.5 Air/Hydraulic Rolling Jack - 7,500 lb. capacity
10355-6 Pair of 6 in. stack extensions for 7.5K rolling jack
10355-9 Pair of 9 in. stack extensions for 7.5K rolling jack
10333-RJ Sprinter adapter kit for 7.5K rolling jack
40230-E Internal air line kit for dual rolling jack operation (4P14EFX, 4015E series only)
40230-X Internal air line kit for dual rolling jack operation (4P14XFX, 4015X series only)
10500SS Stainless Steel Turning Radius Gauges
10500 Powder Coated Turning Radius Gauges
40200-3D Bolt-on alignment kit without turn plates
40200-3DBK Bolt-on alignment kit with powder coated turn plates
Ramps
Part No. Description
10266 36" long Louvered Ramp Kit for drive-thru operation
10266L 48" Ramp Kit for low-profile vehicles
Productivity Accessories
Part No. Description
10267 32 gallon Oil Drain Pan
10342 Hanging tool holder for Oil Drain Pan (Part No. 10267)
10267 32 Gallon Oil Drain Pan Kit (44018 & 44030 only)
10310 Air/electric workstation with filter/lubricator/regulator
3PH4P Power Unit Upgrade to 3-Phase
